Strong posts for heavy vines
Shaoxing Longfan started in 2021. We make fiberglass products. Grape vines get very heavy each year. Metal posts rust. Wood posts rot. So we use solid fiberglass. The diameter is 12 to 16 mm. The surface has spiral grooves. The grooves increase friction with the soil. A vineyard in Xinjiang bought our grape vine support frame for 500 acres of grapes. After 4 years, the posts were still perfect. They said not having to change posts every year saves a lot of labor. We have 14 patents. Our annual production is 3000 tons.
Spiral grooves and stainless steel sleeve
We use solid fiberglass rods. The diameter is 12 to 16 mm. The length is 1.5 to 2.5 meters. The surface has spiral grooves. The grooves run along the rod. They increase friction with the soil. The bottom is sharpened. It is covered with a stainless steel sleeve. The sleeve protects the rod when you hammer it in. The top has a pre-drilled hole. The hole diameter is 8 mm. You put wire or cross bars through the hole. The wire holds the grape vines.
Test data from our lab
We tested the posts in our lab. The table below shows the results.
|
Parameter |
Value / Standard |
|
Tensile Strength |
≥ 600 MPa |
|
Flexural Strength |
≥ 560 MPa |
|
Pull-Out Test |
Inserted 500 mm into soil |
|
Pull-Out Force |
≥ 200 kg |
|
UV Aging |
1,000 hours |
|
Strength Retention |
≥ 88% |
|
Acidic Soil Test |
pH 5.5 for 2 years |
|
Strength Loss |
≤ 5% |
|
Weight vs. Steel Pipe |
1/3 of steel weight |
The spiral grooves increase friction. The vines will not pull the posts out of the ground. Fiberglass resists acid and alkali. It works in all soil types. The pre-drilled 8 mm hole makes it easy to run wire. You can also attach cross bars. The stainless steel sleeve on the bottom prevents splitting. You can hammer the post into hard soil. The sleeve will not crack. The weight is only one-third of a steel pipe. One person can carry many posts. The grape vine support frame is very easy to install.
Long life and no maintenance
The posts do not rust. They do not rot. They do not need paint. They do not need replacement for many years. The vineyard in Xinjiang has used them for 4 years. They are still perfect. The posts are also safe. They do not conduct electricity. There is no risk of lightning. The spiral grooves do not damage the vines. The grooves are only on the underground part. The above ground part is smooth.
Why customers buy from us
We support custom orders. Do you need a larger diameter? Yes, up to 20 mm. Do you need a longer post? Yes, up to 3 meters. Do you need a different color? Yes, we have green and black. FAQ: Will the spiral grooves damage the vines? No, the grooves are only on the underground part. FAQ: Can I use a post driver? Yes, the stainless steel sleeve protects the end. FAQ: How deep should I drive the post? At least 50 cm. The grape vine support frame saves labor for large orchards. Shaoxing Longfan has ISO 9001. We make 3000 tons of fiberglass products each year.
