Built for commercial farming
Shaoxing Longfan started in 2021. We make fiberglass products. Commercial polytunnels need to handle heavy snow and strong wind. Traditional bamboo or wood poles rot in two to three years. We make large-diameter fiberglass tubes. The outer diameter is 20 to 40 mm. The wall thickness is 3 to 5 mm. We use double-layer continuous fiber winding for extra strength. A vegetable farming base in Shouguang, Shandong used our heavy duty polytunnel frame. They said they have not replaced a single pole in 5 years. We have 14 patents. Our annual production is 3000 tons.
Double-layer winding and strong connectors
We use fiberglass tubes with double-layer continuous fiber winding. The ring strength is 250 MPa or higher. The axial strength is 450 MPa or higher. The ends have engineering plastic connectors. The connectors are socket style. You push one tube into another. It locks in place. No tools needed. The surface has an anti-UV and weather-resistant coating. The coating lasts for many years. It does not peel or crack. The poles do not conduct electricity. There is no lightning risk. They are also safe near power lines.
Test data from our lab
We tested the frame in our lab. The table below shows the results.
|
Parameter |
Value / Standard |
|
Flexural Test (ISO 14130) |
1.5 meter span |
|
Load |
200 kg at center |
|
Deflection |
≤ 30 mm |
|
Result |
No permanent damage |
|
Salt Spray Test |
1,000 hours |
|
Result |
No corrosion |
|
Wind Resistance |
120 km/h |
|
Snow Load Capacity |
≥ 50 kg per square meter |
|
Service Life |
≥ 10 years |
The frame has very high load capacity. A single arch can hold 200 kg of concentrated load. That is the weight of two large men. The all-fiberglass structure needs no paint. It needs no maintenance. The socket-style connectors make assembly fast. Two people can put up a large polytunnel in half a day. This is 50% faster than metal frames. The special coating lasts 10 years outdoors. The poles do not rust. They do not rot. They do not get eaten by insects. The heavy duty polytunnel frame is very durable.
Safe and easy to use
The poles do not conduct electricity. This is important for farms. There is no risk of lightning strike. You can also use the frame near overhead power lines. The poles are light. A 3 meter pole weighs less than 2 kg. One person can carry many poles. The connectors are reusable. You can take the frame apart and move it to another field. The poles do not crack in cold weather. They work from -30°C to 70°C.
Why customers buy from us
We support custom orders. Do you need a larger diameter? Yes, up to 50 mm. Do you need a different length? Yes, any length from 2 to 6 meters. Do you need a different connector? Yes, we have T-connectors and cross connectors. FAQ: Can I walk on the frame? No, it is for supporting film only. FAQ: Does it turn yellow in the sun? The coating prevents yellowing. FAQ: How do I clean the poles? Just wash with water. The heavy duty polytunnel frame is maintenance-free. Shaoxing Longfan has ISO 9001. We make 3000 tons of fiberglass products each year.
