Heavy duty stand for big lights
Shaoxing Longfan started in 2021. We make fiberglass products. Professional live streaming needs big octagonal softboxes. Normal light stands cannot hold them. The softbox is heavy. The stand might tip over. So we made a heavy duty stand. The pole is thicker. The base is wider. The lock is double. A photography equipment company in Guangzhou bought our Octagonal Live Streaming Fill Light Stand stands. They use them with 5 kg octagonal lights. The stand does not slip. It does not tip. They said it is professional grade. We have 14 patents. Our annual production is 3000 tons.
Thick tubes and double lock
We use fiberglass tubes with a 25 mm outer diameter. The inner diameter is 21 mm. The wall thickness is 2 mm. The pole is very stiff. It does not bend under heavy loads. The pole has two sections. The height adjusts from 1.0 to 2.2 meters. The lock system has two parts. First, an aluminum threaded lock. You turn it to tighten. Second, a stainless steel spring pin. You push it into a hole. Both locks work together. The pole will not slip down. The base is a heavy tripod. The tripod legs are aluminum. The legs have steel weights. The leg spread is 0.8 meters. Each leg adjusts independently.
Test data from our lab
We tested the stand in our lab. The table below shows the results.
|
Parameter |
Value / Standard |
|
Tube Outer Diameter |
25 mm |
|
Wall Thickness |
2 mm |
|
Flexural Strength |
≥ 530 MPa |
|
Height Range |
1.0 to 2.2 meters |
|
Lock System |
Thread + spring pin |
|
Top Connector |
3/8 inch standard screw |
|
Load Capacity |
5 kg |
|
Base Spread |
0.8 meters |
The stand is very stable. The 0.8 meter leg spread is wide. The steel weights keep it down. The double lock system is safe. Even if one lock fails, the other holds. The threaded lock is strong. The spring pin clicks into a hole. You can hear the click. You know it is locked. The top connector is 3/8 inch. This fits large softboxes and LED lights. The Octagonal Live Streaming Fill Light Stand is very reliable.
Smooth adjustment and easy setup
To adjust height, loosen the threaded lock. Pull the spring pin out. Slide the pole up or down. Release the pin into the next hole. Tighten the threaded lock. The stand is ready. The tripod legs fold up. The whole stand fits into a carry bag. You can take it to different studios. The stand is heavy enough to be stable, but light enough to carry.
Why customers buy from us
We support custom orders. Do you need a taller stand? Yes, up to 2.5 meters. Do you need a different base? Yes, we have a round base with wheels. Do you need a different color? Yes, black only. FAQ: Can I use this with a 10 kg light? No, max load is 5 kg. FAQ: Is the spring pin durable? Yes, tested for 5,000 cycles. FAQ: Does the threaded lock wear out? No, it is made of aluminum. The Octagonal Live Streaming Fill Light Stand is for professional studios. Shaoxing Longfan has ISO 9001. We make 3000 tons of fiberglass products each year
